TP-Link IP PT kamera - C540V (FullColor Dual-Lens, 4MP, 4-12mm, H265+, LED+IR30m, IP66; PoE/12VDC; SD; 2 irányú hang)
Kamera
Képérzékelő
1/3” Progressive Scan CMOS
Shutter Speed
1/3 to 1/10000 s
Slow Shutter
Yes
Min. szükséges megvilágítás
0.005 Lux; 0 Lux with IR/white light
Day/Night Mechanism
IR Cut Filter
Day/Night Switch
Day/Night/Auto/Schedule-Switch
Zoom
3x Mixed Zoom
LENS
Focal Length
4-12 mm (Mixed Zoom)
Aperture
F1.6
FOV
Diagonal FOV: 100°, Horizontal FOV: 84°, Vertical FOV: 46°
Lens Mount
M12*P 0.5
DORI Distance
• 4 mm
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft)
• 8 mm
Detect: 150 m (493 ft)
Observe: 63 m (205 ft)
Recognize: 30 m (98 ft)
Identify: 15 m (49 ft)
PTZ
Pan/tilt Range
Pan: 0° to 332°, Tilt: 0° to 120°
Pan/tilt Speed
Pan Speed:
Configurable from 1° to 55°/s; Preset Speed: 55°/s
Tilt Speed:
Configurable from 1° to 40°/s, Preset Speed 40°/s
Manual Control Speed
Configurable from 8° to 35°/s
Presets
300
Patrol Scan
8 patrols, up to 8 presets for each patrol
Power-off Memory
Yes;
Auto restore to previous PTZ and lens status after power failure
Park Action
Yes;
Preset; Patrol Scan
3D Positioning
Yes
Angle Adjustment (Manual)
Range
Pan: 0° to 332°, Tilt: 0° to 120°
ILLUMINATOR
IR LED
Quantity: 1
Range: 30m
Wavelength: 850nm
White LED
Quantity: 3
Range: 30m
Illuminator On/Off Control
Auto/Scheduled/Always on/Always off
VIDEO
Max. Resolution
2560 X 1440
Main Stream
Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2560x1440, 2304x1296, 2048x1280, 1920x1080,1280x720
Sub-Stream
Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
640x480, 352x288, 320x240
Bit Rate Control
CBR, VBR
Video Compression
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main Stream Supported
H.265 Type
Main Profile
H.265+
Main Stream Supported
Video Bit Rate
Main Stream: 256 Kbps to 4 Mbps
Sub-Stream: 64 Kbps to 512 Kbps
Image Settings
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software
Image Enhancement
BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range
DWDR
SNR
? 52 dB
Image Parameters Switch
Yes
- Webáruház: Techsend webáruház
- Befogadás: Biztonságtechnika > IP kamerák
- Áruk elérhetősége: a kérdésben
- Korszerűsített: 10.5.2025
- Az ár: 56 390 Ft
