TP-link NVR rögzítő - NVR2016H-16MP (16 csatorna, 16 PoE+ port 140W; H265+, 8MP, HDMI, VGA, 2xUSB, 2xSata, audio)
Video and Audio
IP Video Input
16-Channel
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
60 Mbps
HDMI Output Resolution
1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA Output Resolution
1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video Output Mode
HDMI/VGA Simultaneous Output
Multi-View Display
1/4/6/8/9/16
DECODING
Audio Compression
G.711A/G.711U/G.726
Video Compression
H.265+/H.265/ H.264+/H.264
Record Resolution
8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback
16-Channel
Capability
• 25fps:
2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP
• 30fps:
4-ch @ 3MP, 2-ch @ 5MP
Record Management
Record Mode
• Manual Recording
• Scheduling Recording
• Motion Detection Recording
Playback Mode
• Instant Playback
• Regular Playback
• Tag Playback
• Event Playback
Backup Mode
• Regular Backup
• Video Clip Backup
Playback Function
• Play
• Pause
• Stop
• Fast Forward
• Fast Backward
• Play By Frame
• Full Screen
• Video Clip
• Export Clip
• Digital Zoom
• Lock Recording
• Audio On/Off
Hálózat
Szabvány
UPnP (Plug and Play), NTP (Network Timing)
Mobile Phone Access
Android, iOS
Web Browser
Chrome (57+), Firefox (52+), Edge (91+)
Interoperability
ONVIF, CGI
External Interface
Network Interface
1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
USB Interface
1 Front USB 2.0 Port, 1 Rear USB 2.0 Port
Audio Interface
1, Audio In; 1, Audio Out
Alarm In/Out
N/A
Serial Interface
N/A
Power
1× DC Jack
Reset Button
1
Speaker
N/A
eSATA
1
HDMI
1
VGA
1
HARD DISK
SATA
2 SATA Interfaces
Capacity
Up to 10 TB Capacity for Each HDD
PoE
Standard
802.3at/af Compliant
Interface
1-16, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
PoE Budget
140 W Available for All PoE+ Ports, 30 W Max per Port
Alarm
General Alarm
• Motion Detection
• Video Tampering
• Line-Crossing Detection
• Intrusion Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned/Removal Detection
• Vehicle Detection
• Human Detection
• Smart Frame
Anomaly Alarm
• Video Loss
